Grid Inertia
Photo by Ash Amplifies / Unsplash

In our last post, we looked at Grid Operations — the sophisticated, largely automated discipline that keeps electricity supply and demand matched almost instantaneously across complex grid networks.

As noted in that post, the fleet of power generation units that predominantly ran on fossil fuels have historically delivered Inertia to the grid through the physical momentum associated with large rotating devices. Replacing this inertia as fossil fuel is scaled back in the energy mix is one of the less discussed, but most important challenges in the transition to a cleaner energy system.

This post takes a closer look at what Inertia means, why it matters, and how the modern grid is developing new technologies to replicate the effect.

What is grid inertia?

The term comes from classical physics: a spinning object resists changes to its rotational speed. In the context of electrical grids, inertia refers to the stabilising effect of the large rotating masses — turbines, generators, rotors (a.k.a. "Synchronous Generators" or "Alternators") — that have sat at the heart of fossil fuel, nuclear and hydro power plants for over a century.

Running a stable grid requires Grid Operators to ensure demand is met with adequate (and precise) supply almost instantaneously - not just in aggregate but within logical segments of each grid. As discussed in our previous post, this is known as Grid Operations - the process of monitoring, controlling, and maintaining the electrical grid to ensure a reliable, efficient and precise supply of electricity to consumers. Response rates are measured in fractions of a second. High levels of automation apply to routine operations. More urgent intervention can occur where supply and/or demand nodes are adjusted up/down. On occasion, circuit breakers kick in to shed load in given grid segments to preserve supply in more critical segments (e.g. hospital circuits) if a wider outage is at risk of occurrence.

Fig. 1 How rotating turbines provide grid inertia
50 Hz

Rotating mass — turbine and generator rotors weigh hundreds of tonnes and spin continuously at grid frequency (50 or 60 Hz)

Kinetic energy store — the spinning mass holds kinetic energy. If supply drops suddenly, this energy feeds the grid automatically while operators respond

Frequency stabiliser — a heavier, faster-spinning system is harder to slow down, resisting frequency drops and buying critical response time

Typical inertia contribution by plant type (relative)
Coal / gas steam
Very high
Nuclear
Very high
Hydro (rotating)
High
Sync. condenser
Moderate
Wind (DFIG)
Low
Solar PV / battery
None (native)
DFIG = Doubly-Fed Induction Generator, the most common wind turbine type. Synchronous condensers are like retired generator rotors kept spinning to maintain inertia without generating power. Solar PV and battery storage connect via inverters and contribute no physical inertia natively.

In the fossil fuel dominated paradigm, these machines spin in synchrony with the grid frequency and effectively set the heartbeat of the grid by brute force - 50Hz in Europe (50 cycles per second), 60Hz in North America. Devices connected to the grid are designed to operate at that frequency. Deviations — even small ones — can damage equipment; large deviations can cascade into widespread outages.

When something unexpected happens on the grid — a large power plant trips, or demand suddenly spikes — the rotating mass of connected generators acts as a natural buffer. Their kinetic energy continues to feed the grid for seconds, buying time for grid operators and automated systems to respond and restore balance. The greater the total rotating mass connected to the grid, the more instantaneous energy is available. This buffering effect is what engineers mean when they use the term Inertia.

Think of it like a flywheel on a bicycle: the heavier and faster it spins, the longer it keeps the wheel turning after you stop pedalling.

Frequency, Inertia and the rate of change

Grid engineers measure inertia risk through a metric called RoCoF — Rate of Change of Frequency. When a generation unit trips unexpectedly, grid frequency begins to fall according as demand outstrips supply in the milliseconds that follow the loss of supply caused by the trip. The speed at which it falls is the RoCoF. In a high-inertia grid, the physical spinning momentum tends to give operators more time to respond, whereas in a low-inertia grid — (as is the case when inverter-connected renewables predominate) — frequency is at risk of falling faster unless certain measures have been put in place.

Fig. 2 Frequency response following a generation trip — high vs. low inertia
Phase 1
Inertial response
Rotating mass arrests the frequency fall instantly. High-inertia grids fall slowly; low-inertia grids fall fast.
Phase 2
Primary response
Governors and fast-response batteries inject power within seconds to arrest the fall.
Phase 3
Secondary response
Additional generation ramps up over minutes to restore frequency to nominal.
High inertia (fossil / nuclear)
Low inertia (high renewables)
Under-frequency threshold (−0.5 Hz)
Illustrative only. RoCoF = Rate of Change of Frequency. A steeper initial slope indicates lower inertia and greater risk of hitting protection thresholds before primary response can act.

As coal, gas and nuclear plants are progressively retired from the energy mix, the total rotating mass connected to grids falls. Renewable energy sources — solar and wind — are connected to the grid not through rotating generators but through power electronics, specifically devices called inverters. Inverters convert the DC output of solar panels and the variable-frequency AC output of wind turbines into grid-compatible AC power. They are fast, efficient and clean — but they contribute no physical inertia to the grid.

This is the core challenge: the more renewable energy displaces fossil fuel generation, the lower the total physical inertia of the grid, and the more vulnerable it becomes to rapid frequency deviations.

Replacing inertia in the decarbonized grid

The good news is that the engineering community has been working on this problem for some time, and several credible solutions are either in deployment or advancing rapidly. They fall broadly into three categories.

Synchronous condensers are essentially the physical equivalent of the rotating generators of retired power stations. In many1 cases, the old devices have been kept in place, repurposed and kept spinning in situ (meaning that they sit on the same bearings as before). The old engine (usually a powerful steam or gas turbine) is replaced with a much smaller electric motor whose job is to bring these rotating masses up to speed, and then merely maintain them at that speed. They continue to provide physical inertia to the grid — the same stabilising rotating mass — while consuming only a modest amount of power to overcome friction and maintain speed. Several grid operators, including those in the UK, Ireland and Australia, have already deployed synchronous condensers2 specifically to compensate for inertia lost as coal capacity is retired. They are a proven, cost-effective solution in the near term, though they do not generate power — they only provide stability.

Grid-forming inverters represent a more fundamental shift. Conventional inverters (as would connect your home solar/battery) are grid-following — they synchronise or lock-on to the existing grid frequency, relying on that frequency signal to operate correctly. Grid-forming inverters do the opposite: they can actively set and maintain a reference frequency, responding to deviations without waiting for a mechanical signal. Through sophisticated control algorithms, they can emulate the behaviour of a synchronous generator — providing what engineers sometimes describe as synthetic or virtual Inertia. Grid-forming inverters are increasingly being paired with large battery storage systems and are considered central to the long-term architecture of high-renewable grids.

Battery storage with fast-frequency response can be programmed to inject or absorb power within milliseconds of a frequency deviation — far faster than any conventional generator can ramp up. While this is not inertia in the physical sense, it performs much the same function: arresting a frequency fall quickly enough to prevent protective disconnections. The UK's National Grid pioneered this approach with its Enhanced Frequency Response (EFR) programme, contracting battery operators to provide sub-second response to frequency events.

Fig. 3 Grid stability technologies — fossil era vs. the decarbonized grid
Then
Fossil fuel era
Now & ahead
The decarbonized grid
Primary inertia source Rotating turbines & generators in coal, gas and nuclear plants — thousands of tonnes of spinning steel Synchronous condensers (repurposed retired generators) + grid-forming inverters providing synthetic inertia
Peak load response Gas-fired peaker plants — spun up on demand, typically within minutes Battery storage + Virtual Power Plants aggregating distributed energy resources — response in milliseconds
Short-term stability Spinning reserve — turbines idling at low output, ready to ramp; flywheels and condensers Fast frequency response from grid-scale batteries; supercapacitors; demand response via Smart Grid
Frequency control Governor systems on large generators respond automatically to frequency deviations Grid-forming inverters actively set and maintain frequency reference; battery systems arrest deviations in under 1 second
Key characteristics Abundant inertia Slow RoCoF Proven & mature Carbon intensive Fuel dependency Low / zero carbon Fast response Distributed Lower native inertia Technology maturing
Synchronous condensers and grid-forming inverters are in active deployment in high-renewable markets including the UK, Ireland, Australia and parts of Scandinavia. Grid-forming inverter technology is advancing rapidly and is considered a cornerstone of future high-renewable grid architecture.
✅

This is a work in progress. Grid operators in high-renewable markets are navigating a period of genuine complexity. Every national grid that has meaningful renewable penetration has at times resorted to Curtailment3 to ensure that enough synchronous generation remained online to maintain adequate inertia levels. This is precisely the kind of frustrating trade-off that storage and grid-forming technology must ultimately resolve.

The transition from a grid stabilised by the physical inertia of rotating steel to one stabilised by power electronics and smart controls is one of the less visible but most consequential engineering challenges of the energy transition. It is underway, and the pace of development in grid-forming inverters and large-scale storage is impressive.

In our next post, we look at Bottlenecks and their impact — the pinch-points that emerge in grid networks as demand grows and the infrastructure struggles to keep pace.

Footnotes & References

  1. According to Grand View Research in their Synchronous Condenser Market (2025 - 2030) report, refurbished synchronous condensers dominated the market in 2024, accounting for 57.8% of revenue share.
  2. It's worth noting a point on nomenclature in relation to flywheels vs. synchronous condensers, strictly speaking two different devices, but often referred to interchangably. A flywheel is often added to a synchronous condenser to boost its inertial mass — the condenser handles the electrical grid services, the flywheel amplifies the physical inertia it provides.
  3. We'll post on Curtailment in due course, a term used to describe the discarding of energy due to oversupply of electricity from renewable energy sources
